LA115-C402-30MM
- Category: MONO LEVER SWITCH
- Brand: Jigo
- Minimum quantity: 1
- Price: ₹ 1000
The LA115-C402 is a robust 30mm mono-stable lever switch with a wide handle for industrial control applications, offering reliable momentary control and high durability.
Enquire on WhatsAppProduct Details:
Model: LA115-C402
Cut-Out Size: 30mm
Operation Type: Mono-stable (momentary)
Contact Configuration: 2NO (Two Normally Open contacts)
Rated Insulation Voltage: 660V
Conventional Thermal Current (Ith): 10A
Actuator Type: Wide Lever Handle
Build Material: Durable thermoplastic with metal bezel
Mounting: Panel mount with locking nut
Protection Rating: IP65 (front panel, with proper sealing)
Terminals: Screw type
Key Features:
Large 30mm lever for better grip and control
High mechanical life for repeated operations
Simple panel installation with secure locking
Supports high voltage and current operations
Resistant to oil, dust, and water (IP65 front protection)
Reliable spring-return action
Applications:
Industrial control panels
Machine start/stop systems
Operator stations
Automation equipment interfaces
Safety interlocks and manual override systems
