JG-YTT M20-3 Waterproof Cable Connector
The JG‑YTT M20‑3 is a robust nylon cable gland by JIGO, tailored with an M20×1.5 thread. Designed for outdoor and industrial use, it delivers IP68-rated protection, ensuring watertight and dust-tight sealing for cable entries in electrical enclosures.
Product Details
Model: JG‑YTT M20‑3
Thread Size: M20 × 1.5
Cable Diameter Range: 6 mm – 12 mm (standard for M20 size)
Grip Length (GL): 9 mm
Connector Height (H): 27 mm
Spanner Size: 24 mm
Material: Nylon (PA66) for the body; NBR rubber for sealing
Protection Level: IP68 – fully dust-tight and submersible
Temperature Range:
Static: –40 °C to +100 °C (short excursions up to +120 °C)
Dynamic: –20 °C to +80 °C (short bursts to +120 °C)
Color Options: White, Grey, Black
Key Features
Reliably waterproof (IP68) sealing — ideal for outdoor enclosures and harsh environmental conditions
Standard M20 thread and 9 mm cable grip offer secure, adaptable installation
Durable nylon construction provides UV, chemical, and impact resistance
NBR sealing ring ensures long-lasting, leak-free performance
Compact profile with standard spanner size (24 mm) allows easy tool-assisted installation
Applications
Perfect for use in:
Electrical and control panel cable ingress
Outdoor lighting, telecom, and CCTV installations
Renewable energy systems (solar, inverters, battery cabinets)
Industrial automation and machinery cabling
Marine, HVAC, and other wet or dusty environments
Genuine stock from our Ludhiana counter (trading since 1993). GST invoice on every order, courier anywhere in India.
