DISTRIBUTION BOX-280X140X90

    Category: DISTRIBUTION BOXES
  • Brand: Jigo
  • Minimum quantity: 1
  • Price: ₹ 1000

TYP-281409 – IEC529 Standard Weatherproof Distribution Box, size 280×140×90 mm, ideal for compact control setups and safe electrical distribution in industrial or outdoor applications.



Product Details

Model: TYP-281409

Standard: Compliant with IEC529 (Ingress Protection)

Dimensions: 280 mm × 140 mm × 90 mm

Material: High-impact ABS / Polycarbonate / Metal body (as per model variant)

IP Rating: IP65 / IP67 – Dust-tight & water-resistant

Cover Type: Transparent or opaque, available with screw/hinged options

Mounting: Wall / Panel surface mounting with screw slots

Color: Grey or white housing with optional clear cover

Interior Options: DIN rail mountable, terminal block space, ground/neutral bar compatible

Cable Entries: Knockouts or pre-cut gland holes

Key Features

Certified to IEC529 for environmental protection

Compact design with optimized internal volume

Weatherproof and corrosion-resistant build

Ideal for low-voltage distribution or control wiring

Tamper-proof with optional lockable covers

Suitable for indoor and outdoor installation

High UV and impact resistance for long service life

Applications

Electrical distribution in industrial panels

Solar system control junctions

Streetlight or outdoor device enclosures

CNC or automation machine connections

Metering box or relay housing

Compact MCB / MCCB / terminal setups

OEM control solutions in limited spaces
