Phoenix Contact 8 Pin Plug-in Relay 24V DC 2 C/O

This is a Phoenix Contact 8-pin plug-in industrial relay with a 24 V DC coil and 2 changeover contacts (2 C/O), from the Phoenix Contact relay range.

Key features

• 8-pin plug-in base — the relay lifts out and a new one drops in without touching a single wire
• 2 changeover contacts, so one relay switches 2 independent circuits
• 24 V DC coil
• LED on the relay shows when the coil is energised — fault-finding becomes a glance at the rail
• Clear housing, so the contacts and the mechanical flag can be seen working
• Used with the matching 8-pin DIN rail socket and retaining clip

What it is used for

Interposing between a PLC output and a load, isolating control voltage from power voltage, multiplying one output into several circuits, and switching contactor coils, solenoid valves, lamps and alarms. The plug-in base is the point of it: when a relay fails at 2 a.m., the fitter swaps the relay, not the wiring.

8-pin or 14-pin?

An 8-pin relay gives 2 changeover contacts and a 14-pin gives 4. If the circuit needs more than two independent switched paths, or you want spare contacts for a later modification, take the 14-pin.

Buying from Arjun Trading Company

Price is Rs 400 plus GST, relay only — the socket and retaining clip are separate items and we stock both. GST invoice on every order, courier or transport anywhere in India. Call or WhatsApp +91 99887 74490 for the coil voltage and contact rating you need.
