JGLRS-150-5 SMPS Power Supply
- Category: POWER SUPPLY
- Brand: Jigo
- Minimum quantity: 1
- Price: ₹ 1300
The JGLRS-150-5 is a high-power 150W DIN rail-mounted power supply delivering a stable 5V DC output at 30A. It is designed for demanding industrial environments, offering efficient, high-current performance with reliable protections and long service life.
Enquire on WhatsAppProduct Details:
Model: JGLRS-150-5
Input Voltage Range: 85–264V AC, 47–63Hz
Output Voltage: 5V DC
Output Current: 30A
Output Power: 150W
Mounting Type: 35mm DIN Rail
Efficiency: ≥ 84%
Cooling Method: Natural air convection (fanless)
Protection Features:
Overload Protection
Overvoltage Protection
Short-circuit Protection
Housing Material: Flame-retardant plastic
Operating Temperature: -20°C to +70°C
Certifications: CE, RoHS compliant
LED Indicator: Power status LED
Key Features:
High-current output (30A) suitable for heavy-duty 5V applications
Regulated output with low ripple and noise
Built-in safety protections ensure fault-free operation
Space-saving, DIN rail-compatible form factor
Fanless design enables quiet and maintenance-free use
Reliable performance in continuous industrial operation
Applications:
Industrial control panels and automation systems
5V logic systems and embedded computing devices
Large-scale sensor networks and relay boards
High-current communication and networking equipment
Power backup and security systems (CCTV, alarms)
Test benches and R&D equipment requiring 5V/30A supply
