The JGMS-25-12 is a reliable and compact 25W enclosed switching power supply, delivering a regulated 12V DC output at 2.1A. Designed for general-purpose electronics and automation systems, it ensures safe and efficient power delivery in a rugged metal casing.
Model: JGMS-25-12
Input Voltage Range: 85–264V AC, 47–63Hz
Output Voltage: 12V DC
Output Current: 2.1A
Output Power: 25W
Enclosure Type: Metal casing with ventilation slots
Efficiency: ≥ 82%
Cooling Method: Natural air convection
Protection Features:
Overload Protection
Overvoltage Protection
Short-circuit Protection
Mounting Type: Screw-mount (open-frame)
Operating Temperature: -20°C to +60°C
Certifications: CE, RoHS
Clean and stable 12V DC output at 2.1A
Compact, ventilated metal case for better heat dissipation
High reliability and energy efficiency
Wide AC input voltage compatibility
Built-in protection features for safe operation
Easy to integrate into custom enclosures and panels
Industrial electronics and automation systems
12V LED strips and indicators
Embedded devices and sensor modules
Access control and security equipment
Communication equipment and instrumentation
Prototyping, R&D, and test labs
